Country/Region
Tsukuba, Japan
Latitude, Longitude
36.067497, 140.131236
Elevation
69.07573452477192 (m)
| Receiver - Firmware | TRIMBLE ALLOY - 6.21 |
|---|---|
| Antenna - Radome | TRM159900.00 - SCIS |
| Antenna Calibration | ROBOT |
| Clock | INTERNAL |
| Last RINEX Data - Primary Data Center | 2026-10-05 (v3) - None |
| Constellation - RINEX | GPS+GLO+GAL+BDS+QZSS+SBAS |
| Constellation - RealTime | GPS+GLO+GAL+BDS+QZSS |
| DOMES Number | 21797M001 |
| Nearby Tide Gauge | N/A |
| Download Type | Link |
|---|---|
| Station Log (ASCII) | TKBG00JPN.log |
| Station Log (GeodesyML) | TKBG00JPN.xml |
| Global Data Center | Link |
|---|---|
| CDDIS | CDDIS Data |
| Wuhan University | Wuhan University Data |
| ESA | ESA Data |
| IGN | IGN Data |
| KASI | KASI Data |
| SOPAC | SOPAC Data |
For a list of other data centers, visit IGS Data Access
| Receiver - Firmware | Antenna - Radome | Date |
|---|---|---|
| TRIMBLE ALLOY - 6.21 | TRM159900.00 - SCIS | Oct. 16, 2023 |
| TRIMBLE ALLOY - 5.37 | TRM159900.00 - SCIS | June 23, 2022 |
| Sender | Subject | Date |
|---|---|---|
| Possible co-seismic displacements: ISHI, TKBG, | Aug. 23, 2026, 10 p.m. | |
| Possible co-seismic displacements: BADG, BJFS, | July 30, 2025, 10 p.m. | |
| Yui OGAWA | ALL JAXA STATION(CMUM00THA, CPNM00THA, DAE200KOR, | Dec. 24, 2024, 1:51 a.m. |
| David Maggert | New IGS Station: TKBG00JPN | Feb. 26, 2024, 3:29 p.m. |
Analysis Center Usage
| AC | Final | Rapid | Ultra |
|---|---|---|---|
| GFZ | Sept. 20, 2026 |
